A traditional waffle pod floor made from recycled and waste plastic delivering a “Circular Foundation”, protecting the environment, and supporting sustainable construction.
FILLING THE VOID
A circular foundation for the future
THE CLEVA POD® SYSTEM
Easy to install and ideal for residential, commercial, and industrial buildings.
CLEV-1100/220 | CLEV-1090/300 | CLEV-1090/225
CLEVA POD® 220/225/300
CLEVA POD® is a patented forming system for concrete waffle pod slab foundations made from recycled plastic. It is an environmentally friendly, cost-effective alternative to polystyrene raft waffle POD or slab on grade concrete foundations. The CLEVA PODs® are exactly the same size as the traditional poly pod however the CLEVA PODs® stack snuggly and securely together.
CLEVA POD END CAP™
The unique CLEVA POD® END CAP is incorporated into the CLEVA POD® and can be cut off the main pod to close the void and prevents the ingress of concrete when a straight cut to shorten the pod is required.
CLEV-C1100/220 | CLEV-C1090/300 | CLEV-C1090/225
CLEVA BAFFLE™ 220/225/300
1100mm x 220mm
A specifically designed baffle that locks into the horizontal and vertical structural grid pattern on the underside of the POD. The CLEVA BAFFLE™ converts a normal CLEVA POD® into a versatile POD able to be cut on any angle and around any intrusion such as plumbing pipes. The CLEVA BAFFLE™ prevents the ingress of concrete into the void under the CLEVA POD®.
CLEV-S
CLEVA POD® SPACER™
300mm x 300mm
The CLEVA POD® SPACER™ is designed to form 100mm wide internal ribs. A unique element of the CLEVA POD® system is that the SPACER™ is designed to sit on top of the CLEVA POD® base flange. Once the reinforcing bar is located into the spacer, the weight of the reinforcing bar prevents the CLEVA POD® from lifting when the concrete is being poured. Lifting is a constant issue with polystyrene pods as the concrete slurry that finds its way under the pod causes the polystyrene pods to float.
Siting the CLEVA POD® SPACER™ on top of the CLEVA POD® base flange also prevents the SPACER™ from cutting into and penetrating the DPM.
The foundation’s internal ribs can be increased in size in multiples of 100mm by adding the clip-on SPACER™ extender.
CLEV-US
CLEVA POD® UNI SPACER™
100 x 300 x 400
The CLEVA POD® UNI SPACER™ is designed to provide flexibility in the positioning of the CLEVA POD® allowing for multiple separation distances.
CLEV-SE
The CLEVA POD® SPACER EXTENDER™
The foundation’s ribs can be increased in size in multiples of 100mm by adding the clip-on CLEVA POD® SPACER EXTENDER™ giving the positioning of reinforcing greater flexibility.
CLEV-P
CLEVA PLUG™
35mm x 8mm
A simple connector plug is used to secure the CLEVA BAFFLE™ to the CLEVA POD® on any angle and join multiple CLEVA BAFFLEs™ together.
